LogUI build 60 reads iOS, iPadOS, macOS and other logarchives

Until now, LogUI has only been able to access the active log of your Mac, by reading it directly. There are occasions when you can’t do that, or want to preserve the log for future reference. You also can’t browse the log directly on any of Apple’s devices. In these cases, and others, the best solution is to make a logarchive, and browse that instead. I’m delighted to provide an update to LogUI that can browse logarchives, including those created in iOS, iPadOS, and on Apple’s other devices.

What is a logarchive?

A logarchive is an undocumented package containing copies of all the files from the active log at the moment the logarchive was created. They can be opened and browsed by Console, Consolation 3, Ulbow, the log command tool, and now by LogUI. Because they contain all the files that make up the log, they can be large, and typically range in size from about 300 MB to over 1 GB. All the files containing log entries are stored in their original binary tracev3 format, proprietary to Apple, and again undocumented, although that format has been reversed in the past.

Create a logarchive

The easiest way to create a logarchive is to run a sysdiagnose, and that’s the standard way for saving a logarchive on one of Apple’s devices. Methods vary by device, and include:

On a Mac, use the System Diagnostics… option in Activity Monitor’s Action tool, or press the Shift, Command, Control, Option and . keys at the same time, or run sudo sysdiagnose -f ~/Documents to save it to your Documents folder.
On an iPhone or iPad, press and hold both volume buttons and the side or top button at the same time, for about 2 seconds. This combination may trigger other features, though. The sysdiagnose file will be made available in Settings > Privacy & Security > Analytics & Improvements > Analytics Data, from where you can transfer it to your Mac.

Unpack the .tar.gz archive resulting from that, and you’ll find a system_logs.logarchive inside it.

On a Mac, you can instead use the log collect command to create a logarchive directly. For example,
log collect –output ~/Documents/my.logarchive –last 5m
collects the last 5 minutes of log in the specified logarchive package. macOS security will block you from trying to save that logarchive on an external volume, though.

My free log browser Ulbow uses another method for assembling logarchives, and the next build of LogUI will incorporate that and other tools for working with logarchives.

Browse a logarchive in LogUI

This new build of LogUI has a seventh tool, to Use Logarchive. Click on that and you’ll be prompted to select the logarchive to open and browse.

Because the dates and times used in the logarchive will be different from current clock time, the LogUI window displays red warning text just to the left of the Start time. Set the date and time to a period within the scope of that logarchive, and use the Get Log tool as normal.

The log excerpt shown in the screenshot above is taken from the kernel boot sequence of my iPhone 15 Pro, to demonstrate how this all works.

If you want to return that window to browsing the active log, click on the Use Logarchive tool again, but this time cancel the selection. Other windows will of course continue to browse the active log unless you set them to use a logarchive as well.

Coming soon

Although browsing saved log entries in a logarchive is exactly the same as those of the active log, dates and times can be a pain. If you want to check when log files in a logarchive were written, use the Finder’s contextual menu to show their contents, scroll to the foot of the folders inside, select the Persist folder and check the file creation dates there.

This is made even easier in the forthcoming new build of LogUI, which features a Logarchive Tool to help you navigate logarchives, and learn which date and time ranges are appropriate.

LogUI 1.0 build 60 is now available from here: logui160
and from its Product Page.

I’ll be along with a new build in a few days, once I have tested and documented its Logarchive Tool. In the meantime, I hope you’ll find LogUI useful for studying the first beta-releases of Apple’s new operating systems.
